When connected to a compatible Audio Authority driver, the 9880 provides pristine component video, digital coaxial audio, analog L/R audio, plus an IR jack. The cable length compensation adjustment allows the installer to fine tune image and sound quality over long Cat 5 runs.

The Model 9880 is perfect for wall-mounted displays. Cable connections are parallel to the wall, allowing near-flush mounting for flat panel displays. The 9880 can be mounted on any flat surface, even to the back of a TV when no wall surface is available.

• Enclosed design does not require a wall box for mounting
• Cable length compensation adjustment allows the installer to fine tune image and sound quality over long Cat 5 runs
• Rear facing IR jack
• Compatible with: Models AVX-661, AVX-561, AVP-11, 1170, 1171, 1176, 9871, 9870, 9880T

The 9880 is one of three Cat 5 receivers compatible with Audio Authority residential Cat 5 products. Use any combination of receivers in the same system for the perfect mix of logistics and aesthetics. View a Cat 5 receiver comparison table.


** Caution ** Always correctly pair and terminate Cat 5 cables, and test pairing and continuity before connecting power to the driver and wallplate. Incorrect cable termination, or plugging a cable into the wrong port can result in wallplate damage.




Product Dimensions: (H-W-D, inches)

• 1.75 x 3.75 x 3

Documentation

• Product Focus Sheet: 9878, 9879, and 9880 Active Cat 5 Receivers (.pdf)
