The 9880T incorporates the key signal paths necessary for premium audio and video entertainment, plus an IR pathway for easy remote control of AV components. All this over just two inexpensive, easy to install Cat 5 cables. The Model 9880T Cat 5 Transmitter distributes HDTV signals up to 1,000 feet from the source to any of three receiver options.

The Infrared Pathway
The 3.5mm IR jacks provide convenient access for a third party IR remote distribution network over the passive, three-wire pathway on the Cat 5 cable. IR receiver and emitter equipment is not included.


Top Quality Over Long Cable Runs
Our Active Gain Equalization technology allows adjustable compensation for any cable length up to 1,000 feet from the source. The adjustment is made at the remote end so that the installer can fine tune the results while viewing the results on the HDTV. Like our commercial video distribution products, the UniDrive provides reliable ground isolation, preventing hum bars and other artifacts associated with ground loops.


To the Home Owner
While the UniDrive is ideal for new construction or an existing home, it does require special knowledge and tools to install. We suggest you contact a local custom home installation specialist. Many installation specialists are members of the Custom Electronic Design & Installation Association and can be located through the CEDIA website.


Product Dimensions: (H-W-D, inches)

• 9880T Transmitter: 1.75 x 3.75 x 3

Downloads

• UniDrive (9880T) User Manual (PDF file)
