Flexible Input Options for SonaFlex Audio Systems



FlexPort audio transmitters provide remote inputs for SonaFlex audio systems via Cat 5e/6 cable. You can configure the Override button on the FlexPort module to play the connected source on one or more outputs. Each FlexPort Transmitter adds up to four additional audio inputs (2 per FlexPort input) to each SF-16M.  FlexPort modules can be located up to 500 feet from the SF-16M, and can be installed as a wallplate or on any flat surface.

SF16mnlillustration1
FPM-B

FlexPort Modules can be mounted on any flat surface, in standard work boxes, or in “open ended” single gang brackets such as Arlington model LV1 or Carlon model SC100RR.


FPM-XFPM-XXLR/ 1/4” TRS Input with Phantom Power
  • Accepts any 3-wire balanced line or mic level audio input via a combo XLR/ 1/4” TRS input
  • Override button (defeatable) with backlighting to indicate audio override status
  • 15V phantom power (defeatable) for condensor microphones
  • Input gain potentiometer
  • Input can be assigned as Dual Mono (2 mono channels), Mono 1 or Mono 2 on the FlexPort audio bus
  • Optional “Mix” setting allows two FlexPort modules to be mixed together on a single FlexPort audio bus (both inputs must be assigned to a mono channel)

See an application example.

FPM-BFPM-B

Balanced Line/Mic Input with Phantom Power

  • Accepts any 3-wire balanced line or mic level audio input
  • “Override” contact closure input for push-to-talk paging mics such as Bogen model MBS1000A
  • Override button (defeatable) with backlighting to indicate audio override status
  • 15V phantom power (defeatable) for condensor microphones
  • Input gain potentiometer
  • Input can be assigned as Dual Mono (2 mono channels), Mono 1 or Mono 2 on the FlexPort audio bus
  • Optional “Mix” setting allows two FlexPort modules to be mixed together on a  single FlexPort audio bus (both inputs must be assigned to a mono channel)

See an application example.

FPM-UFPM-UAnalog Audio Input
  • Accepts any analog RCA audio input
  • Override button (defeatable) with backlighting to indicate audio override status
  • Input can be assigned as Stereo (default), Mono 1 or Mono 2 on the FlexPort audio bus
  • Optional “Mix” setting allows two FlexPort modules to be mixed together on a single FlexPort audio bus (both inputs must be assigned to a mono channel)
FPM-DFPM-DDigital Coax/Optical Input
  • Accepts any digital SPDIF coax or optical audio input (Stereo PCM only)
  • Override button (defeatable) with backlighting to indicate audio override status
  • Input can be assigned as Stereo (default), Mono 1 or Mono 2 on the FlexPort audio bus
  • Optional “Mix” setting allows two FlexPort modules to be mixed together on a single FlexPort audio bus (both inputs must be assigned to a mono channel)
  • Analog audio output (pass-thru) for applications where a converted analog output is desired

More Information:
