Using IR Commands with the SF-16M




The spreadsheet contains over 4000 discrete commands that can be used in third party IR remote systems to control a single SF-16M or up to four units in one system. It's easy to find the commands you need if you refer to the structure at right.

The IR codes work with any programmable remote that uses hex codes ("Pronto" codes). Simply open the file in Microsoft Excel or other spreadsheet application, copy a hex code and paste it into the remote control setup application. The codes are organized as shown in the examples.




Download Discrete IR Codes Discrete IR Codes (1.73 MiB) for SF-16M Matrix Amplifier


SonaFlex

Visit  SF-16M Product Page




The spreadsheet is organized as follows:


SECTION
Global commands
  • All outputs, all units
 EXAMPLE

  • Input 16, all outputs, all units
Unit 1
  • Unit 1 global commands
  • Unit 1 group commands
  • Unit 1 individual commands
  • Unit 1 scene commands
 .
  • SF-16M unit 1, volume up, all outputs
  • SF-16M unit 1, volume up, output 13
  • SF-16M unit 1, volume up, group 9
  • SF-16M unit 1, recall scene 7
Unit 2
  • Unit 2 global commands
  • Unit 2 group commands
  • Unit 2 individual commands
  • Unit 2 scene commands
 .
  • SF-16M unit 2, volume up, all outputs
  • SF-16M unit 2, volume up, output 13
  • SF-16M unit 2, volume up, group 9
  • SF-16M unit 2, recall scene 7
Unit 3
  • Unit 3 global commands
  • Unit 3 group commands
  • Unit 3 individual commands
  • Unit 3 scene commands
 .
  • SF-16M unit 3, volume up, all outputs
  • SF-16M unit 3, volume up, output 13
  • SF-16M unit 3, volume up, group 9
  • SF-16M unit 3, recall scene 7
Unit 4
  • Unit 4 global commands
  • Unit 4 group commands
  • Unit 4 individual commands
  • Unit 4 scene commands
 .
  • SF-16M unit 4, volume up, all outputs
  • SF-16M unit 4, volume up, output 13
  • SF-16M unit 4, volume up, group 9
  • SF-16M unit 4, recall scene 7
