[Image for 013-072]
Stainless blue illuminated push-button
Stainless Blue Button (No Harness)
013-072

[]

Audio Authority's stainless steel round buttons with blue illumination provide an attractive, simple interface for demonstration systems. Harness sold separately. Compatible with Access, DirectSelect, and other Audio Authority demo systems.


Categories: PSB


[Pins]
Pins
[Front]
Front
[Installed]
Installed

This stainless steel, momentary switch is ideal for attractive retail demo systems. A blue LED illuminated ring invites customers to select products and adjust volume and music tracks. Attaches to all Audio Authority switching systems when combined with harness.

Specifications:
  • Hole size: 0.75 inch (19 mm)
  • Outer diameter: 0.9 inch (22.5 mm)
  • Maximum panel thickness: 0.5 inch (12.5 mm)
  • Required depth: 2 inches behind front panel surface
  • Illumination: blue LED (ring)
  • Harness not included



999s-dimensions
