[Image for 1512]
Audio and Video Hub

8x12 Audio/Video Intercom Hub

Model 1512 - New Model Available

Features:
  • 8 x 12 capacity
  • Expandable card cage
  • (2) Counter Station cards - Model 1515
  • (3) Lane Station cards - Model 1516
  • (1) System card - Model 1517SD
  • Power supply

Categories: Discontinued

  • Performs all voice/video signal routing functions for multi-lane systems
  • Accommodates audio/video and/or audio-only Counter and Lane Stations
  • Typically located in telephone closet or under a counter
  • System settings are stored on a removable media card (proprietary format) for security or replication purposes
  • Capacity easily expanded
  • Tough steel enclosure containing Counter, Lane, and System cards designed to be wall-mounted
  • Multimedia source devices (digital and/or analog) can play advertising content whenever the lane is idle
  • Direct outputs from wide angle camera and/or lane cameras for surveillance recording




    FAQ - About the new style Hub
    • Q: What is different?
      A:
      The Series III hub cards are completely compatible with legacy systems, but when used with other Series III components and connected by shielded UTP cable, the new grounding scheme protects the system from interference and power fluctuations. System card now accepts digital audio and video input via the HDMI port.

    • Q: What if I need to replace existing cards in the field?
      A: You can mix and match hub cards, and update the firmware to the latest version, as long as the firmware is at least 4.0 or later.

Downloads

  • Drawings
    • Template  (221.83 KiB) Drawings for Import Full scale line drawings in DWG and PDF formats for import into CAD.
  • Manuals
