4x8 Audio/Video Intercom Hub
Model 1511 - New Model AvailableThe 1511 Audio/Video Hub supports up to four Counter Stations and eight Lane Stations.
Categories: Discontinued
The 1511 Hub configuration can be easily upgraded with additional Counter Cards or Lane Cards.
- Performs all voice/video signal routing functions for multi-lane systems
- Accommodates audio/video and/or audio-only Counter and Lane Stations
- Typically located in telephone closet or under a counter
- System settings are stored on a removable media card (proprietary format) for security or replication purposes
- Capacity easily expanded
- Tough steel enclosure containing Counter, Lane, and System cards designed to be wall-mounted
- Inputs allow multimedia source devices to play advertising content whenever the lane is idle
- Direct outputs from wide angle camera and/or lane cameras for surveillance recording
Downloads
- Drawings
- Template
(221.83 KiB) Drawings for Import Full scale line drawings in DWG and PDF formats for import into CAD.
- Template
- Manuals
- Series 1500 Manual
1.77 MiB Series 1500 Installer's Reference Guide
- Series 1500 Manual
