Integrated Audio and Video Hub

8x16 Audio-Video Intercom Hub

Model 1513A

Features:

Categories

The 1513A Hub configuration can be easily upgraded with additional Counter Cards or Lane Cards.

Performs all voice and video signal routing functions for multi-lane systems
Accommodates audio-video and/or audio-only Counter and Lane Stations
Typically located in telephone closet or under a counter
System settings are stored on a removable media card (proprietary format) for security or replication purposes
Capacity easily expanded
Tough steel enclosure containing Counter, Lane, and System cards designed to be wall-mounted
Inputs allow multimedia source devices to play advertising content whenever the lane is idle
Direct outputs from wide angle camera and/or lane cameras for surveillance recording

Downloads

Drawings
- Template (221.83 KiB) Drawings for Import Full scale line drawings in DWG and PDF formats for import into CAD.
Manuals
- Series 1500 Manual 1.77 MiB Series 1500 Installer's Reference Guide
