[Image for 1816-1]
1816-1 RS-232 Distributor with USB
RS-232 Distributor (USB)
Model 1816-1

[]

Features:

  • Distributes serial commands to six devices
  • Feedback on one output
  • Compatible with BrightSignŽ and other devices
  • 3.5mm serial outputs and input (null modem)
  • USB serial input (1816-1) with power via USB
  • Version with 3.5mm serial input available (Model 1816)
  • 1.15 x 3.25 x 6.88 inches (mounting tabs included)
  • Tough plastic case

Categories: Interactive Switching, Modules, Accessories

[Top view]
Top view





Synchronize up to Six Outputs

The Model 1816-1 receives RS-232 commands via USB, and echoes the data to 6 outputs simultaneously. Position 1 is also capable of receiving feedback from a connected sink device and passing
the data back to the source device.



 brightsign-xd

BrightSignŽ Authorized Partner






Specifications:

USB input port

RS-232 Outputs: 3.5mm (straight)

Power pass-through to other 12V devices

Dimensions (HxWxD, inches): 5.63 x 3.25 x 1.15

Input Voltage/Polarity: 12VDC center positive
